Boat Lifts




  • Aluminum and stainless steel construction
  • Choice of beveled carpeted wooden bunks or optional extruded aluminum bunks.
  • Unique computer designed drive pipe extrusions with 2 1/2" nylatron bushings and zerk fittings.
  • Cable tensioners on all cable winders.
  • Unique computer designed sheave extrusions require no welding.
  • Thru-bolted design secures both the web and the flange to the cradle.
  • Exclusive safety bar on the sheave extrusions prevent sheave bolt rotation.
  • Stanchion brackets are firmly secured to the cradles with custom-made stainless steel U-bolts.
  • Massive 5" x 1 1/2" CNC-machined sheaves with maintenance-free 50,000# psi UC-200 bushings.
  • Cable deadman is symmetrically supported by both channels.
  • Cables, cable winders, top and bottom beams, drive pipes, chock brackets, and sheaves are the largest, strongest and safest in the industry.
  • Grooved 3" cable winders with safety collar.
  • Ten-year structural warranty with true product insurance.

  • Stern platform, walk board, aluminum bunks and direct drive winches are available. Cable tensioner with 3" cable winder.
    Dog-leg cradles are available for low water installations. Stanchion with custom stainless steel U-bolt and unique sheave extrusion.
    INTRODUCING THE MOST SENSIBLE BOATLIFT EVER...
    Priced right with standard extras and options not normally seen ...until now.


    Optional PSI direct drive power unties for faster cradle travel. Custom dog-legged cradles for low water situations.
    Custom bearing extrusions with Nylatron bushings. Custom cradle platform with bunks for multiple jet skis.
