Boat Lifts

  • Aluminum and stainless steel construction
  • Choice of beveled carpeted wooden bunks or optional extruded aluminum bunks.
  • Unique computer designed drive pipe extrusions with 2 1/2" nylatron bushings and zerk fittings.
  • Cable tensioners on all cable winders.
  • Unique computer designed sheave extrusions require no welding.
  • Thru-bolted design secures both the web and the flange to the cradle.
  • Exclusive safety bar on the sheave extrusions prevent sheave bolt rotation.
  • Stanchion brackets are firmly secured to the cradles with custom-made stainless steel U-bolts.
  • Massive 5" x 1 1/2" CNC-machined sheaves with maintenance-free 50,000# psi UC-200 bushings.
  • Cable deadman is symmetrically supported by both channels.
  • Cables, cable winders, top and bottom beams, drive pipes, chock brackets, and sheaves are the largest, strongest and safest in the industry.
  • Grooved 3" cable winders with safety collar.
  • Ten-year structural warranty with true product insurance.

  • Stern platform, walk board, aluminum bunks and direct drive winches are available. Cable tensioner with 3" cable winder.
    Dog-leg cradles are available for low water installations. Stanchion with custom stainless steel U-bolt and unique sheave extrusion.
    Priced right with standard extras and options not normally seen ...until now.

    Optional PSI direct drive power unties for faster cradle travel. Custom dog-legged cradles for low water situations.
    Custom bearing extrusions with Nylatron bushings. Custom cradle platform with bunks for multiple jet skis.
